Techness RUN 100 - Explose Diagram

18
EXPLODED DIAGRAM
Item
Factory
code
Description
Specification
Qty.
N01
bottom steel bracket
steel
1
N02
041800001
Φ60 moving wheel
Φ60*25
2
N03
052500002
adjustable cushion
Φ44.2*35
4
N04
040800003
end cap
for 20*20*T1.5 tube
1
N05
020100004
cup head hex screw
M8*45 tooth: 20
8
N06
021000001
flat washer- Class C
Φ8
31
N07
022000002
1 non-metal hex nut
M8
12
N08
040300017
console lower cover
715*350*27.5
1
N09
039040011
safety key
1
N10
020900002
hex screw
M10*28
2
N11
080000006
running deck
1125*556*T15
1
N12
020800001
cross pan screw
ST4.2*13
2
N13
filter fixed plate
1
N14
main steel bracket
steel
1
N15
020800002
cross screw
ST4.2*13
13
N16
020500017
cross pan screw
M6*25
2
N17
020200004
hex screw
M8*80 full tooth
2
N18
040200001
left end cap
111.5*106*77.5
1
N19
040200002
right end cap
111.5*106*77.5
1
N20
031300021
button board
8PIN, 150mm
1
N21
0530000012
running deck rubber plate
45*33*T3.0
4
N22
052000001
rubber cushion
Φ30*20
2
N23
040800008
30*20 end cap
for 30*20*1.5 tube
2
N24
020200003
hex screw
M8*55 full tooth
1
N25
040800004
40*25 end cap
for 40*25 tube
2
N26
032800002
speed sensor
900mm 2PIN
1
N27
049900058
position plate
φ18*φ8.5*T3.2
2
N28
026200001
gas spring
10KG, 644mm
1
N29
tube
20*20*1.5*361mm
1
N30
020100002
cup head hex screw
M8*35 full tooth
1
N31
motor support bracket
steel
1
N32
053000007
motor cushion plate
100*92.5*T1.5
1
N33
020000013
hex blot
M8*30
2
N34
020300001
hex bolt
M8*12 full tooth
4
N35
020300002
hex bolt
M8*35, tooth: 15
2
N36
030000003
motor
1.75HP, 180V
1
N37
051000001
v-belt
180J
1
N38
036000004
filter
6vv1(7251-4)
1
N39
transformer plate
1
N40
036500002
reactor
T5817-1 ACL-2.5mH-6A
1
N41
tube
steel
1
N42
031100041
lower controller
AC220V, B306V03
1
N43
033700001
on/off switch
250V AC/8A
1
