Technibel Climatisation SCDV106C5VAC - Boperating Range

b) OUTDOOR UNIT (LITTLE BAG)
MODEL
FAN & FAN MOTO
R
Propeller Propeller Propeller
Number / Diameter mm 1 / ø 320 1 / ø 380 1 / ø 380
No of pole / rpm (220 V, high) 4 / 1205 6 / 860 6 / 860
Nominal output W 58 70 70
BLU-BRN: 249 ÷ 287 BLU-BRN: 218 ÷ 251 BLU-BRN: 218 ÷ 251
BLU-BLK: 270 ÷ 311 BLU-BLK: 230 ÷ 265 BLU-BLK: 230 ÷ 265
Safety device Internal type
Open °C 150 ± 10
Close °C Automatic
µF 2.0 2.5 2.5
VAC 450 450 450
THERMISTOR (COIL SENSOR) TH3 NTC SENSOR
Resistance (at 25 °C) kΩ 10 ± 1%
HEAT EXCHANGE COI
L
Coil Aluminium plate fin / Copper tube
Rows 2 2 2
Fin pitch mm 1.6 1.6 1.6
Face area
m
2
0.227 0.290 0.290
Setting
Run capacitor (C2)
Coil resistance (at 25 °C) Ω
B
OPERATING RANGE
COOLING MODELS
Temperature Indoor air intake temperature Outdoor air intake temperature
Maximun 32 °C DB / 23 °C WB 46 °C DB
Minimum 19 °C DB / 14 °C WB 19 °C DB
HEAT PUMP MODELS
Temperature Indoor air intake temperature Outdoor air intake temperature
Maximun 32 °C DB / 23 °C WB 46 °C DB
Minimum 19 °C DB / 14 °C WB 19 °C DB
Maximun 27 °C DB / 19 °C WB 24 °C DB / 18 °C WB
Minimum - DB / - WB -8 °C DB / -9 °C WB
Cooling
Cooling
Heating
5
SCDV106C5
SCDV136C5 SCDV106R5
