11 - "ECH" ELECTRONIC CONTROL
Microprocessor control module, including:
-
chilled water temperature control (water inlet),
- control of operating parameters,
-
self-adapting algorithm for water volume reduction,
- circulating pump control (frost protection and anti-sticking function),
- dynamic setpoints are possible according to the outside temperature (to be activated at the time of installation by means
of special parameterization).
- anti-short cycle system,
- hour counter compressor and circulating pump,
- alarm management,
- anti-freeze security (temperature probes at water exchanger outlet),
- digital display of:
.
water temperature,
. set-point,
.
alarm code (HP, LP, water output, probes, anti-freeze...).
- remote alarm reporting is possible via a potential-free contact,
-
integrated condensation pressure control (with pressure sensors),
- remote control with display unit (accessory),
- serial communications port (RS 485 interface, accessory) - MODBUS Protocol.
12 - INSTALLATION INFORMATION
See details in the installation manual.
12.1 - INSTALLATION
Protection index of the unit:
- IP 24 : for the electrical equipment,
(IPXXB : for the mechanical hazards).
Before installation, verify the following points:
- the unit must be installed outside in an appropriate location and in compliance with environmental requirements (sound
level, integration, etc...),
- the water chiller’s installation location must be perfectly level and strong enough to support the weight of the unit and
must have adequate inundation protection,
- sufficient space around the unit should be provided in order to facilitate servicing and maintenance operations,
- air suction to the coil and fan discharge must not be obstructed,
- install the unit above the region’s average snowfall level,
- vibrations and noise must not be transmitted to adjacent buildings,
- install the machine on anti-vibration pads and fit hoses on piping elements, as required,
-
if necessary, consult an acoustics specialist concerning the unit’s optimum location,
-
4 holes Ø 22.5 enable to place hoisting hooks and lift the unit.
12.2 - ELECTRICAL CONNECTIONS
All required information is indicated on the electrical diagram provided with the unit and in the installation manual.
Connections are to be made in compliance with the standard code of practice and as per the standards in force at the site
of installation.
12.3 - HYDRAULIC CONNECTIONS
The hydraulic connections are to be made in compliance with the standard code of practice.
IMPERA
TIVE:
Install the filter supplied on the water inlet of the unit.
12.4 - STARTING - MAINTENANCE
Refer to the installation guide and the maintenance manual.
IMPORT
ANT
:
-
The unit's electronic control features a frost protection device that automatically starts the water circulating pump
depending on the outside temperature (adjustable threshold), even if the unit is turned off.
- In the event the unit may be taken out of service or in the case of a high risk of freezing:
- either drain the installation,
-
or add glycol to the circuit.
- Tank anti-freeze resistance:
its electrical power supply and control must be separate from those of the unit.
