CHGV 50 CHGV 64 CHGV 72 CHGV 80
2 2 2 2
kg 2 x 7.25 2 x 8 2 x 9 2 x 12.5
• • • •
Number 2 2 2 2
Power supply 400V / 3 / 50Hz
• • • •
Nominal current per compressor A 17.00 20.80 23.10 23.80
Nominal power consumed by the compressor kW 9.90 12.50 14.30 14.70
• • • •
Number 2 2 2 2
Air flow
m
3
/h 9,800 11,000 11,000 11,000
Diameter mm 760 760 760 760
Max. rotation speed (motor) rpm 620 660 660 660
Power consumption per motor kW 0.75 0.85 0.85 0.85
• • • •
Number 2 2 2 2
• • • •
Number 2 2 2 2
Water capacity liters 4 5 6 7
Male 1"1/2 coupling (40x49)
Minimum installation water volume * liters 120 160 170 200
Maximum installation water volume ** liters 1,500 1,500 1,500 1,500
Expansion tank (1.5 bar)
Tank capacity liters 18 18 18 18
Safety valve (3 bar) with pressure gauge
Differential water output pressure switch
Fill valve (ø 1/4" female)
Water filter supplied (not installed)
Maximum power consumption (pump only) kW 1.40 1.40 1.90 1.90
Maximum current A 2.70 2.70 3.50 3.50
Power supply 400V / 3 / 50Hz
Electrical equipment IP 24 IP 24 IP 24 IP 24
Mechanical risks B B B B
Hermetic SCROLL compressor with soundproofing and internal
thermal protection
Cooling circuit (number) with HP and LP pressure switches
R 407 C refrigerant charge
Helicoidal electric fan, direct coupling, with internal thermal protector
General electrical power supply 400V / 3N + Earth / 50Hz
Equipment protection index
Water exchanger with stainless steel brazed plates AISI 316 L with
thermal insulation
Air exchanger with protective grille, copper tubes, aluminium fins
230V / 1 / 50Hz power supply with speed control for condensation
pressure control
Nominal current per motor (single-phase 230 VAC)
(*)
If the water volume of the system is below the minimum, a buf
fer tank must be installed.
(**)
If the water volume of the system is above the maximum, an additional expansion tank is required.
