Technibel CHGV 64 - Technical Characteristics; Power Supply Details; Nominal Operating Conditions; Operating Limits

4
3 - TECHNICAL CHARACTERISTICS
CHGV 50 CHGV 64 CHGV 72 CHGV 80
kW 47.60 62 67 78
kW 20.60 26.40 28.80 29.40
(EER) 2.31 2.35 2.33 2.65
kW 25 32 36 36.6
A 42.80 56.30 60.40 64.80
A 38.70 47.70 54 55.50
A 170 185 225 225
mm
2
16 16 25 25
m
3
/h 8.21 10.66 11.52 13.43
L/s 2.28 2.96 3.20 3.73
kPa 220 160 180 90
Electrical supply cable section
Nominal water flow
Available pressure
Model
Heating capacity
Nominal power consumption *
Effictuiveness heating *
Rated total input amperage
Total Max. power consumption **
Total Max. current consumption **
Starting current
(*) Gross value without hydraulic pump.
(**) In the operating range.
•
Power supply:
400V (±10%) / 3 Ph + Neutral + Earth / 50Hz
•
Nominal operating conditions:
- water inlet temperature : + 12°C
- water outlet temperature : + 7°C
- outdoor dry bulb temperature (dry) : + 35°C
•
Operating limits (pure water):
- temperature of inlet air to condenser : - 10°C to + 45°C
- water outlet temperature : + 4°C to + 20°C
•
Water system pressure: 1.5 to 3 bar.
Consult us for any special climatic conditions departing significantly from the nominal conditions.
