Technicolor TG582n - Plug in Your Modem

6
3
4
DSL
1 2 3 4
Reset
2
1
• PlugtheotherendofthegreyDSLcableintotheendofthelter
marked “ADSL”.
• Plugoneendoftheblackpowercableintothemodemandthe
other end into the wall socket. Turn on the power at the wall.
Power plug
Filter with
ADSL port
Grey DSL cable
Phone
Jackpoint
DSL port
Plug in your modem
• PlugoneendofthegreyDSLcableintotheDSLportonyourmodem.
Black power cable
3
