Technics SA-C600

112
Others
Specifications
(Continued)
■
GENERAL
Power supply AC 120 V, 60 Hz
Power consumption 46 W
Power consumption
in standby mode
(Network Standby
Off & No clock
display)
0.15 W
Power consumption
in standby mode
(Network Standby
On & No clock
display)
2.0 W
*
1
Dimensions
(W×H×D)
340 mm × 94 mm ×
341 mm
(13
25
/
64
” × 3
45
/
64
” ×
13
7
/
16
”)
Mass Approx. 4.8 kg (10.6 lbs)
Operating
temperature range
0 °C to 40 °C
(+32 °F to +104 °F)
Operating humidity
range
35 % to 80 % RH
(no condensation)
*
1: Wired LAN or Wireless LAN
■
AMPLIFIER SECTION
Output power
60 W + 60 W
(1 kHz, T.H.D. 1.0 %, 4 Ω,
20 kHz LPF)
FTC output power
40 W + 40 W
(1 kHz, T.H.D. 1.0 %, 4 Ω,
20 kHz LPF)
Load Impedance 4 Ω - 16 Ω
Frequency Response
PHONO (MM)
20 Hz - 20 kHz
(RIAA DEVIATION ±1 dB,
8 Ω)
LINE 20 Hz - 40 kHz (-3 dB, 8 Ω)
DIGITAL 20 Hz - 80 kHz (-3 dB, 8 Ω)
Input sensitivity/
Input impedance
LINE 650 mV / 31 kΩ
PHONO (MM) 6.5 mV / 47 kΩ
