Control reference guide
This unit (rear)
1110
21
18 1914
12 13
15 16 17 20
10 FM ANT terminal
(⇒ 22, 41)
11 PHONO EARTH terminal
(⇒ 54)
• For connecting the ground wire of a turntable.
12 Analog audio input terminals (PHONO)
(⇒ 54)
• Please use the cable less than 3 m.
13 Analog audio input terminals (LINE)
(⇒ 54)
14 USB-B terminal (PC)
(⇒ 52)
• For connecting to a PC, etc.
15 LAN terminal
(⇒ 28)
16 Coaxial digital input terminals (COAX)
(⇒ 50)
17 Optical digital input terminal (OPT)
(⇒ 50)
18 Subwoofer terminal
19 Speaker output terminals
(⇒ 23)
20 Product identification marking
• The model number is indicated.
21 AC IN terminal (
)
(⇒ 25)
