34 N.C. O Unused/Free, Release H output
35 N.C. O Unused/Free, Release H output
36 N.C. O Unused/Free, Release H output
37 N.C. O Unused/Free, Release H output
38 N.C. O Unused/Free, Release H output
39 N.C. O Unused/Free, Release H output
40 N.C. O Unused/Free, Release H output
41 N.C. O Unused/Free, Release H output
42 N.C. O Unused/Free, Release H output
43 N.C. O Unused/Free, Release H output
44 N.C. O Unused/Free, Release H output
45 N.C. O Unused/Free, Release H output
46 N.C. O Unused/Free, Release H output
47 N.C. O Unused/Free, Release H output
48 N.C. O Unused/Free, Release H output
49 N.C. O Unused/Free, Release internal pull-up for resistance H output
50 N.C. O Unused/Free, Release internal pull-up for resistance H output
51 N.C. O Unused/Free, Release internal pull-up for resistance H output
52 N.C. O Unused/Free, Release internal pull-up for resistance H output
53 N.C. O Unused/Free, Release internal pull-up for resistance H output
54 EXT DAC O Initialization diode, Internal pull-up resistance
55 EXT RON O Initialization diode, Internal pull-up resistance
56 DTS 2 O Initialization diode, Internal pull-up resistance
57 INIT I Initialization diode, Reading input
58 N.C. I Unused/Free, Connect to GND through resistance
59 N.C. I Unused/Free, Connect to GND through resistance
60 N.C. I Unused/Free, Connect to GND through resistance
61 N.C. I Unused/Free, Connect to GND through resistance
62 N.C. I Unused/Free, Connect to GND through resistance
63 N.C. I Unused/Free, Connect to GND through resistance
64 CDOUT I CS4226:CDOUT Serial data input
65 CS42 O CS4226:CS Tip select
66 SCLK O Main-Sub Serial clock output for communication
67 TXD O Main-Sub Serial data output for communication
68 RXD I Main-Sub Serial data input for communication
69 /CS49 O CS49326:CS CS49326 Tip select
70 CCLK O CS49326/CS4226/CS4341:CCLK Serial clock
71 CDIN O CS49326/CS4226/CS4341:CDIN Serial data
72 SCOUT I CS49326:SCDOUT Serial data input
73 AVSS - Power analaog for conversion of A/D, Connect to GND
74 VREF - Reference voltage for conversion of A/D
75 VOLUME A/D Volume position detection for A/D
76 REQS I Main-Sub Communication
77 POWER O DSP Power control L:ON H:OFF
78 REQM O Main-Sub Communication
79 PON O CD4226:PDN CS4226/CS4341 Reset
80 CSRESET O CS49326:RESET CS49326 Reset
