SOUND PROCESSOR
1 EQ/SFP section
MANUAL GEQ
5-Band EQ
Center frequency
Level control
€Q/Space mode
7O/300/1 k/3.15 k/40 k HZ
2.0, 4.0, 6.0 dB
4 modes HEAVY, CLEAR, SOFT, HALL
SUPER 3D AIEQ
3 modes Al EQ, SUPER 3D Al 1, SUPER 3D Al 2
VCR (EXT) 250 mV/15 kK
VDP (AUX) 250 MV/15 kQ
Output level
VCR REC OUT 150 m¥/1.5 kQ.
{For areas except the United Kingdom, Continental
Europe, Russia, Australia and N.Z.)
VIDEO OUTPUT
MONITOR OUT 1 Vp-pi75Q
VCR REC OUT 1 Vp-pi75Q
@ DOLBY PRO LOGIC section
PRO LOGIC mode SURROUND
CENTER mode NORMAL
DELAY TIME
m AV SURROUND section
AV surround mode
SUPER SURROUND(MUSIC, MOVIE)
m@ DSP CONTROL section
DSP control made
20 ms (Fixed)
SUPER SOUND EQ
CENTER FOCUS.
VIRTUAL REAR SURROUND
MULTI REAR SURROUND
SEAT POSITION
lm Spectrum analyzer section
Display mode NORMAL, PEAKHOLD, AURORA
M General
Dimensions (WxHxD) 29389270 mm
Mass
1.6
kg
TUNER AMPLIFIER
B Amplifier section
Power output (L/R both channel driven)
Stereo Mode
DIN 1 kHz THD 1 %/6 Q (High) 2x25 W
100 Hz THD 1 %/8 Q (Low) 2x45 W
RMS 1 kHz THD 10 %/6 © (High) 2x35 W
100 Hz THD 10 %/8 © (Low) 2x65 W
PRO LOGIC mode
DIN FRONT
1 kHz THD 1.%/6Q (High) 2X26 W
100 Hz THD 1 %/8O (Low) = 2x45 W
SURROUND 1 kHz THD 4 %/8.O 2x30 W
CENTER = 1 kHz THD 1 %/8. 0 60 W
RMS FRONT
4 kHz THD10 %/6 Q (High) = 2x35 W
100 Hz THD 10 %/8.Q (Low) 2x65 W
SURROUND 1 kHz THD 10 %/8 Q 2x40 W
CENTER = 1 KHz THD 10 %/8.Q 80 W
PMPO 1 kHz/High 6 Q, Low 8.0
CENT, 8 2, SURR, 8 © 3000 W
Total harmonic distortion
Rated power at 1 kHz 1% (6.Q)
Half power at 1 kHz 0.1 % (6.0)
Load impedance
FRONT (High) 60
FRONT (Low) Bo
SURROUND 8a
CENTER BQ
DIGITAL 8. WOOFER
Center frequency 60 Hz
LEVEL (VOL —20 dB) MID +3 dB
MAX +6 dB
@ FM tuner section
Frequency range 87.60—-108.00 MHz
{0.08 MHz steps)
Sensitivity 4.8 WV (IHF usable)
S/N 26 dB 1.5 pV
S/N
MONO 70 dB (75 dB, IHF)
Antenna terminal(s) 75. (unbalanced)
@ AMtuner section
Frequency range
522-1629 kHz (8 kHz steps)
520-1630 kHz (10 kHz steps)
Sensitivity (S/N 20 dB) 500 UV/m
m@ Timer section
Clock
Function
Quartz-lock type
Play timer (4 time, daily},
Rec timer (1 time, daily),
Sleep (120 min, 30 min intervals)
Setting Intervals (Play/Rec)
1 minute--23 hours 59 minutes
(i min intervals)
General
Power supply
(For the United Kingdom, Australia and N.Z.)
AC 230-240 V 50 Hz
(For Continental Europe and Russta)
AC 230V 50 Hz
AC 110/127/220-230/240 V 50/60 Hz
230 W
{For others)
Power consumption
Standby
(For the United Kingdom, Continental Europe,
Russia, Australia and N.Z.) 0.5W
(For others) 1.0 W
Dimensions (WxHxD) 293x118,5x343 mm
Mass 5.3 kg
DVD/VIDEO CD/CD CHANGER
@ Discs played
DVD-Video disc
8/12 cm single-sided. single-layor
8/12 em single-sided, doubto-layer
8/12 cm double-sided, double-layer
(One layer per side)
Compact disc (CD-DA, Video CD) 8/12 om disc
CD-R/CD-RW 8/12 cm disc
@ Audio
No. of channels 5.1 channel (FL, FR, SL, SR, C, SW)
@ Video
Signal
system
PAL
625/50,
PAL
525/60,
NTSC
Output level
Composite video 1 Vp-p (75 QO)
S-video ¥ 1 Vp-p (75 Q)
S-video C 0.300 Vp-p (75 2) PAL
0.286 Vp-p (75 Q) NTSC.
@ Pickup
Beam source Semiconductor laser
Wavelength 658/790 nm
(For Norge)
Bolgelengde 658/790 nm.
Laser-styrke Ingen farlig straining sendes ut
Mm General
Dimensions (WXHXD)} 293x89x 288 mm
Mass 2.5 ke
CASSETTE DECK
Deck system Stereo cassette deck
Track system 4 track, 2 channel
Recording system AC bias
Bias frequency 100 kHz
Erasing system AC erase
Heads
Deck 1
(Playback head) Permalloy head
Deck 2
(Recording/Playback head) Permalloy head
(Erasing head) Double gap ferrite head
Motors
Deck 1,2
Capstan drive DC servo motor
Tape speed 4.8 cm/s
Wow and flutter 0.16 % (WRMS)
Fast forward and rewind times
Approx. 140 seconds with C-60 cassette tape
Frequency response (Dolby NR off)
TYPE I (NORMAL) 20 Hz—-16 kHz (DIN}
TYPE Il (HIGH) 20 Hz-16 kHz (DIN)
TYPE IV (METAL) 20 Hz—-16 kHz (DIN)
SAN (Signal level=max recording level, TYPE 1 type
tape)
NR off 56 dB (A weighted)
Dolby B NR on 66 dB (A weighted)
Input sensitivity and impedance
REC (IN) 150 mv/23 kQ
Output voltage and impedance
PLAY (OUT) 280 mV/360 Q
™@ General
Dimensions (WXHXD) 204 118,5X281 mm
Mass 24 kg
FRONT SPEAKER
Type 8 way, 3 speakers, Bassretlex
Speaker(s)
Super woofer 17 om cone type
Woofer 42 cm cone type
Tweeter 6 cm ring shaped dome type
Impedance High 6 Q
Low 8
Input power (Music) High 60 W
Low 120 W
Output sound pressure level 87 dBW (1.0 m)
Crossover frequency 120 Hz, 4 KHz
Frequency range 42 Hz~60 kHz (—16 dB)
46 Hz--36 kHz (- 10 dB)
@ General
Dimensions (WxHxD) 240% 412% 269 mm
Mass 5.8 kg
CENTER SPEAKER
Type 2 way, 3 speakers, Bassretlex
Speaker
Wooter(x2) 8 cm cone type
Tweeter 6 cm cone type
Impedance 80
Input power (Music) 160 W
Output sound pressure level 86 dB/W (1.0 m)
Crossover frequency 4 kHz
Frequency range 100 Hz~22 kHz (—16 dB)
416 H2—20 kHz (--10 dB)
@ General
Dimensions (WXHXD) 190x99x 166 mm
Mass 1.8 kg
SURROUND SPEAKER
Type 1 way, 1 speaker, Closed
Speaker
Full range 8 om cone typo.
Impedance Ba
Input power (Music) 70W
Qutput sound pressure level 84 dBW (1.0 m)
130 Hz—-20 kHz (--16 dB)
150 Hz--18 kHz (— 10 dB)
Frequency range
li General
Dimensions (WXHXD) 140x99x 118 mm
Mass 0.9 kg
Low" and “High” stand for low frequency and
high frequency.
1. Specifications are subject to change without
notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the
digital spectrum analyzer.
