Technics SD-s3300 User Manual

F
Front
Panel
Controls
and
Functions
(continued)
Graphic
equalizer
SH-801
7
@
Powerlequalization
switch
(POWER)
The
power
and the
equalization
effect
can be
switched
on and
olf.
ON:
Set
to this
position
for equalizer
correction.
OFF:
Set to
this
position
to bypass
the equalizer.
When the switch
is in the
"OFF"
position,
signals
will still
pass
through
this unit
unalfected by
the
front
panel's
band-level
con-
trol settings.
By
turnirig this
switch on
and otf,
the equalizer
effect
dif-
ferences
can
also be
checked.
@
Left channel
band-level
controlslindicators
(LEFT
CHANNEL)
These
conlrols
are used
to adiust
lhe
7 frequency
levels
that
resull from dividing
the
63 Hz-16
kHz
frequency
range
into 7.
When
these
levels are
moved
in the
"+
dB"
direction,
peak
frequency
characteristics
are obtained.
When
they are
moved
in the
"
-
dB" direction,
dip
lrequency
characteristics
are ob-
tained.
These characterislics
can
be
emphasized
or al-
tenuated
a maximum
of
12 dB.
When the
pofler
switch
is
set
to lhe
"ON"
position,
the
tip of
these
levels will
illuminate.
@
Right
channel
band-level
controlslindicators
(RTGHT
CHANNEL)
These conlrols are
used to adjust
the 7 trequency
levels
tE
result lrom dividing
the 63
Hz- 16 kHz lrequency
range intoT-
When these
levels are moved
in
the
"+
dB" direction,
peat
frequency characteristics
are obtained.
When they are
mod
in the
"
-
dB" direction,
dip
frequency characteristics
are
G
tained,
These charactelistics
can
be emphasized or *
tenuated a
maximum of
12
dB.
When the
power
switch
is set to the
"ON" position,
the tipd
these levers
will illuminate.
@
lnput selector
(INPUT
SELECTOR)
SOURCE:
Set to this
position
to listen
to the
radio or
a compact
disc,
TAPE:
Set to
this
position
to
listen
to the second
cassetle
deck
VCR connected
to the
graphic
equalizer.
18
