8. Schematic Diagram Notes
- This schematic diagram may be modified at any time with the
development of new technology.
Notes:
S501:
Power standby/on switch ( /I)
S503:
Bass down switch (BASS )
S504:
Bass up switch (BASS )
S505:
VGCA (variable gain control amplifier) switch (VGCA)
S506:
Treble down switch (TREBLE )
S507:
Treble up switch (TREBLE )
VR501:
Input selector VR (INPUT SELECTOR)
VR502:
Volume control VR (VOLUME)
- Indicated voltage values are the standard values for the unit
To Next Page
