Technics SL-PS670D

Compact Disc Player
tise
pieimaL AUDIO AA AAS HH *
multi-stage nolse shaping
RAE1100Z MECHANISM SERIES
Specifications
B Audio
No. of channels
Frequency response
2 (left and right, stereo)
2 — 20,000 Hz, + 0.5 dB
Output voltage 2 V (at 0 dB)
Dynamic range 98 dB
S/N 107 dB
0.002% (1 kHz, 0 dB)
0.0027% (1 KHz, 0 dB)
Harmonic distortion
Total harmonic distortion
Wow and flutter - Below measurable limit
DA converter MASH (1 bit)
Output impedance 600 2
Load impedance More than 10 kQ
Headphone output level 15 mW max. 32 Q (adjustable)
@ Pickup
Wavelength 780 nm
Laser Power No hazardous radiation is emitted
(with safety protection)
ORDER NO. MB9410050C2
Service Manual
Compact Disc Player
SL-PS670A
Colour
Areas
Model No.
elem |
m@ General
Power consumption 15 W
Power supply AC 50/60 Hz, 230 ~ 240 V
Dimensions (W x Hx D) 430 x 114x290 mm
Weight 4.0 kg
Note:
Specifications are subject to change without notice.
Weight and dimensions are approximate.
For United Kingdom only:
This apparatus was produced to BS 800.
*
@ MASH is a trademark of NTT.
