<ID>: Netherlands, Danish,
<IE>: English
- The parenthesized indications in the Remarks columns specify the
areas. (Refer to the cover page for area.)
- The marking [RTL] indicates that Retention Time is Limited for this
item. After the discontinuation of this assembly in production, the
item will continue to be available for a specific period of time. The
retention period of availability is dependenton the type of
assembly, and in accordance with the laws governing part and
product retention. After the end of this period, the assembly will
no longer be available.
- All parts are supplied by MESA.
Ref. No. Part No. Part Name & Description Pcs Remarks
1 RHD30035-K1 SCREW 4
2 RKM0036D-K TOP CABINET 1
3 XTBS3+8JFZ1 SCREW 17
4 RGW0201-K KNOB,VOLUME 1
5 RHD30070 SCREW 1
6 RKA0053-A FOOT 4
7 RMG0332-K RUBBER 2
8 RGP0389G-K1 FRONT PANEL 1
9 RGB0031-A TECHNICS BADGE 1
10 RGL0184A-Q1 PANEL LIGHT 1 1
11 RGL0185A-Q PANEL LIGHT 2 1
12 RGL0229-Q PANEL LIGHT 3 1
13 XTW3+15T SCREW 2
14 RGU0887A-K2 BUTTON,SPEAKER 1
15 RGU0889-K BUTTON,TONE 1
16 RGU1038A-K BUTTON,SELECTOR 1
17 RGU1685-K BUTTON,POWER 1
18 RGW0177A-K KNOB,TONE 3
19 RHD26017 SCREW 11
20 RHD26018 SCREW 1
21 RHN90001 NUT 4
22 RMR1181-K COVER 1
24 XTB3+20JFZ SCREW 7
25 XTB3+8JFZ SCREW 8
A1 RJA0019-1X AC POWER SUPPLY / CORD 1
(E,EG) /
A1 RJA0053-2X AC POWER SUPPLY / CORD 1
(EB) /
A3 RQCB0169 SERVICE CENTER / LIST 1
A4 RQT4663-1E INSTRUCTION MANUAL 1 (E)<IA>
A4 RQT4664-1R INSTRUCTION MANUAL 1 (E)<IB>
A4 RQT4665-1D INSTRUCTION MANUAL 1 (EG)<IC>
A4 RQT4666-1H INSTRUCTION MANUAL 1 (EG)<ID>
A4 RQT4667-1B INSTRUCTION MANUAL 1 (EB)<IE>
16
