R801
ERDS2FJ103
1
/
4W
10K
1
Ref. No. Part No. Part Name & Description Pcs Remarks
R803 ERDS2FJ103 1/4W 10K 1
R805,06 ERDS2FJ103 1/4W 10K 2
R807 ERDS2FJ104 1/4W 100K 1
R808-10 ERDS2FJ103 1/4W 10K 3
R811 ERDS2FJ821 1/4W 820 1
R812 ERDS2FJ102 1/4W 1K 1
R813 ERDS2FJ122 1/4W 1.2K 1
R814 ERDS2FJ152 1/4W 1.5K 1
R815 ERDS2FJ182 1/4W 1.8K 1
R817 ERDS2FJ221 1/4W 220 1
R818-20 ERDS2FJ561 1/4W 560 3
R822 ERDS2FJ821 1/4W 820 1
R823 ERDS2FJ102 1/4W 1K 1
R825 ERDS2FJ473 1/4W 47K 1
R826 ERDS2FJ181 1/4W 180 1
R827 ERDS2FJ331 1/4W 330 1
R828 ERDS2FJ102 1/4W 1K 1
R829 ERDS2FJ103 1/4W 10K 1
R830 ERDS2FJ472 1/4W 4.7K 1
R831 ERDS2FJ331 1/4W 330 1
R832 ERDS2FJ105 1/4W 1M 1
R833 ERDS2FJ334 1/4W 330K 1
R834 ERDS2FJ103 1/4W 10K 1
RL601,02 RSY0013-0 RELAY 2
RL751 RSY0015M-0 RELAY 1
S401 ESB68047 SW,TONE 1
S801-06 EVQ21405R SW,PUSH 6 EVQ21405RJ
S807 RSP2B026-A SW,PUSH 1 K0F122A00139
S808,09 EVQ21405R SW,SPEAKER A/B 2 EVQ21405RJ
T1 RTP2M5B005 POWER TRANSFORMER 1
ETP68VRU71EA / (EB)
T1 RTP2M5E001 POWER TRANSFORMER 1
ETP68VRU61DA / (E,EG)
VR471,72 EVJYA1F04C15 VR,BASS/TREBLE 2
VR501 RRV16B05B15A VR,VOLUME 1 D2BHD15Y0002
VR502 EVJ02QF04G15 VR,BALANCE 1
X801 EF0EC4004T4 OSCILLATOR 1 EFOEC4004T4
16. Cabinet Parts Location
