Turntable (not included) [3]Connect the flat cables.
[3-t] Connect the 3-core flat cable
Household AC outlet (included with the tuner).
oe [3-2] Connect the 3-core flat cable
Tuner
CONTROL
AC
OUTLET
(included
with
the
cassette
tape
deck).
AMPLIFIER —\ [ae
(not included)
~AC IN
[4]Connect the AC power supply cords.
Connect this cord only after all other cables and
cords have been connected.
Notes:
1. The configuration of the AC outlet and AC power
supply cord differs according to area.
ae
Except [EG] area) - 2. Connect the AC power supply cord included with a
He
(
compact disc player to the AC outlet of the
[3-2] 4 amplifier as illustrated below in either case:
¢When a graphic equalizer does not have the AC
Graphic equalizer AC OUTLET outlet.
(not included)
When a graphic equalizer is not used in combina-
tion with these components.
Amplifier
Compact disc player AC OUTLET AC OUTLET
(not included)
~AC IN
LJ Gat
Compact disc player
AC OUTLET
)
~AC IN (e2)
Ly; a a |
@ About the AC outlets of the each components
Do not connect video-related equipment (such as a TV, etc.) to the AC outlets of
these components. (These outlets are especially for audio equipment.) Also do not
exceed the indicated power ratings when connecting to these outlets.
° “SWITCHED” outlet (For tuner)
Power is controlled by the power switch.
¢ “UNSWITCHED” outlets (For amplifier, compact disc player, graphic
equalizer)
Power is always available, regardless of power switch setting.
