Part XIII MIDI
181
QQTG0692
MIDI
Control Messages
Enable or disable the exchange of various control data.
1.
On the MIDI MENU display, select CONTROL
MESSAGES.
• The display looks similar to the following.
• The CONTROL MESSAGES display consists
of 3 pages. Use the PAGE buttons to switch
between pages.
2.
Use the MESSAGE ▲ and ▼ buttons to select
the control message.
3.
Use the ON and OFF
∧
and
∨
buttons to spec-
ify on or off for the control message.
ON:
Data for the control operation is exchanged.
OFF:
Data for the control operation is not
exchanged.
• The BANK SELECT setting is effective only
when PRG. CHANGE is set to ON.
• The EFFECT & REVERB setting controls the
DIGITAL EFFECT, CHORUS, MULTI and
REVERB on/off.
• RPN is the general term for KEY SHIFT,
TUNING, PITCH BEND RANGE and MODU-
LATION SENSITIVITY.
4.
Repeat steps 2 and 3 for each control as
desired.
Realtime Messages
Enable or disable the exchange of START/STOP data (REALTIME COMMANDS), and select the CLOCK
mode.
1.
On the MIDI MENU display, select REALTIME
MESSAGES.
• The display looks similar to the following.
2.
Use the buttons on the left side of the display
to select a function.
3.
Use the VALUE
∧
and
∨
buttons to change
the setting.
REALTIME COMMANDS
ON:
Rhythm and SEQUENCER start/stop, con-
tinue, and song position pointer data can be
transmitted/received.
OFF:
This data cannot be transmitted/received.
CLOCK
INTERNAL:
This instrument’s internal clock is used to
control the perform-ance. The clock of the
connected equipment is disabled.
MIDI:
The clock of the connected equipment is
used to control the performance. This
instrument’s clock is disabled. (The tempo
is displayed as “
q
= − − −.”)
• The CLOCK is set to INTERNAL when the
power to this instrument is turned on.
4.
Repeat steps 2 and 3 for the other function if
desired.
18_Part XIII.fm 181 ページ ２００３年２月５日 水曜日 午後２時０分
