Technify Motors Cessna 172 User Manual

Supplement Airplane Maintenance Manual
Cessna 172 with TAE 125-02-99 / -114
AMM-20-02
Chapter:
Issue:
Issue Date:
Page:
Content:
20-AMM-73-02
3
06.11.2013
2
10
Rev. No:
Rev. Date:
1
25.08.2014
Feed Pump
The feed pump is an intake-camshaft driven gearwheel pump
which provides the HPP with diesel or jet-fuel with a pressure of
3-5 bar (43.5 psi to 72.5 psi).
The main components are two counter rotating gear wheels
which mesh with each other when rotating, whereby fuel is
trapped in the chambers formed between the gearwheels and is
transported to the outlet. Due to the camshaft drive, the delivery
quantity is proportional to the engine speed. See Figure 2.
Figure 2 Fuel Feed Pump
1Suction End
2Drive Gear
3 Pressure end
1
2
3
