Connections
CONNECTIONS
For the 32G22B-HD, 32G22B-HD/DVD, 32G22B-FHD and 40G22B-FHD models only.
A
C
D E
F
G
H
I
J
B
Earphones Earphone Output
Ethernet/LAN* Network Connection
Digital Optical Audio Digital Optical Audio output
YPbPr HD input (YPbPr)
HDMI 1 HDMI input (ARC)
HDMI 2 HDMI input
RF IN RF / TV Aerial Input
HDMI 3 HDMI input
2 x USB USB port
AV IN Audio/Video Input
CI CARD IN Common Interface module
A
I
B
J
C
D
E
F
G
H
K
Y
Pb
Pr
*The Ethernet/LAN port is used only for Pay TV services and Freeview HD (Freeview services are only
available in the UK). It is not intended to be used for internet/network use.
