Technika DAB1101ST - Controls and Connectors; Front Panel Controls; Top Panel Controls; Rear Panel Connections

3
CONTROLS AND CONNECTORS
1
FRONT
TOP
BACK
2
15
16
17 18
DAB/
FM
BACK/
SCAN
1/6 2/7 3/8
4/9 5/10 PRESETINFO/
MENU
ENTER
VOL-
SLEEP
VOL+
3 4 5 6
10
11
12
13
14
9
7 8
1
FRONT
TOP
BACK
2
15
16
17 18
DAB/
FM
BACK/
SCAN
1/6 2/7 3/8
4/9 5/10 PRESETINFO/
MENU
ENTER
VOL-
SLEEP
VOL+
3 4 5 6
10
11
12
13
14
9
7 8
1. LCD display
2. DAB/FM button
3. BACK/SCAN
4. 1-6 preset button
5. 2-7 preset button
6. 3-8 preset button
7. VOLUME +/- controls
8. SLEEP /
button
9. Telescopic aerial
10. INFO/MENU button
11. ENTER button
12. 4-9 preset button
13. 5-10 preset button
14. PRESET button
15. POWER switch
16. DC power input
17. EARPHONE output
18. Battery compartment
