38
8.1 Connecting the speaker unit
> Connect the red speaker cable (+) to the speaker connection marked L+ or R+
(A) on the radio unit and tighten using a suitable fl at-bladed screwdriver (B).
> Then connect the black speaker cable (-) to the speaker connection marked
L- or R- (A) on the radio unit and tighten using a suitable fl at-bladed screwdriver
(B).
Only use connection cables with wire end sleeves or rigid wire.
- Playback is always in mono, even in 2-speaker mode (2nd speaker not included
in the scope of delivery; can be obtained from specialist dealers as an accessory).
- Loudspeaker cables and mains voltage lines must be separated from each other
inside the fl ush-mounted box by suitable measures (either by fi xing them with a
cable fastener or using an insulating tube).
- It is not permi ed to lay loudspeaker cables and mains voltage lines together
outside the fl ush-mounted box. Separation must be ensured by suitable
measures (e.g. separately in the empty conduit).
