42
8.3 Final assembly
> Both units (speaker and radio unit) are then inserted into the existing fl ush-
mounted sockets and screwed in position with suitable fi xing material (not
included).
Ensure that the speaker and radio unit are aligned correctly. Both units are
marked with TOP/OBEN.
> A er installing the radio unit and speaker, the frame (not included) is fi xed by
a aching the speaker cover and the control unit. To do this, push the speaker
cover and the control unit gently and carefully onto the speaker and radio unit
until they click into place.
Only switch the power back on once fi nal assembly has been successfully
completed. The operating unit must not be mounted/removed if the power is on.
This can lead to device defects.
