13
EN
4 Connections
a Connection of the satellite antenna to the LNB input.
b Connection of the cable connection (digital and/or analogue) or the DVB-T antenna to the
antenna input of the TV set.
c Connection of the TV set to a DVD player by:
- an HDMI connection cable or
- a SCART connection cable or
- a Cinch component cable
d Scart connection of the TV set to a video cassette recorder.
a
b
d
DVD
Video cassette recorder
c
Radio TV
HDMI 1
IN
Video
SVideo
L
Y
U
R
R
L
SPDIF
OPT
IN
OUT
IN
L
HDMI 2
IN
USB
IN
IN
Service
DC 5V
max. 30mA
DC 13/18V
max. 0.4A
AERIAL
CABLE
S
M
A
R
T
C
A
R
D
C
O
M
M
O
N
I
N
T
E
R
F
A
C
E
