Channels 2
Bits per sample 16
Sampling rates 32.0, 44.1, 48 KHz
Connection S-Video input (Hosiden)
Input signal level Y: 1Vss/75Ohm
C: 0.3Vss/75Ohm
Audio R/L Cinch
Connection Video Input
Video Cinch
Audio R/L Cinch
Connection - Scart socket (AV 1/AV 2)
Input
Audio R/L
Function switching voltage 0...2 V TV off
4.5...7 V Picture size 16:9
9.5...12 V Picture size 4:3
Input signal level R: 0.7 Vss/75Ohm
G: 0.7 Vss/75Ohm
B: 0.7 Vss/75Ohm
Audio input level R/L 0,5 V r.m.s. (nominal)
Audio input impedance >40 KOhm
Connection component input
Input signal level Y: 1.0 Vss/75Ohm
Pr: 0.7 Vss/75Ohm
Pb: 0.7 Vss/75Ohm
Connection- VGA input
Supported resolutions 640x480, 800x600, 1024x768, 1366x768
Supported timing VGA/DVI for VESA standard:
Native resolution of the panel for VGA/DVI output for the following timing (VESA CVT):
The HDTV formats 720p and 1080i at 50 and 60Hz are additionally supported via the DVI(HDMI) input.
Mode Resolution
Horiz.
freq.in
kHz
Vert.
freq.
in Hz
Sync-
Pol.
H/V
Pixels
gross
Active
pixels
Sync-width
H/V
(Pixels)
Frontporch
H/V
(Pixels)
Backporch
H/V
(Pixels)
Pixel
cycle
in MHz
Native
1360*768
@50Hz
39,564 49,892 -/+ 1744*793 1360*768 136 / 5 56 / 3 192 / 17 69
Mode Resolution
Horiz.
freq.
in kHz
Vert.
freq.
in Hz
Sync-
Pol.
H/V
Pixels
gross
Active
pixels
Sync-
width H/V
(Pixels)
Frontporch
H/V
(Pixels)
Backporch
H/V
(Pixels)
Pixel
cycle
in MHz
VGA
640x480
@60Hz
31,469 59,94 -/- 800*525 640*480 96 / 2 16 / 10 48 / 33 25,175
SVGA
800x600
@56Hz
35,156 56,25 +/+ 1024*625 800*600 72 / 2 24 / 1 128 / 22 36
SVGA
800x600
@60Hz
37,879 60,317 +/+ 1024*628 800*600 128 / 4 40 / 1 88 / 23 40
XGA
1024x768
@60Hz
48,363 60,004 -/- 1344*806 1024*768 136 / 6 24 / 3 160 / 29 65
68
