TechniSat TECHNIPLAYER LP 200 - Technical Specifications

22
Technical specifications
Technical specifications
We reserve the right to make technical modifications and
correct errors.
The dimensions are approximate values.
Directives and standards
Directives and standards
This product conforms to
• the Low-voltage Directive (2014/35/EU),
• the EMC Directive (2014/30/EU) and
• CE Marking Directive.
Dimensions
(width x height x depth):
435 mm x 121.5 mm x 372 mm
Weight:
3.9 kg
Voltage:
230 V AC, 50 Hz
Power consumption:
2 W
Ambient conditions:
+5 °C to +35 °C
45 % to 85 % relative humidity
(non-condensing)
Stylus tip:
Diamond stylus
System:
Magnetic system
Wow, flutter
< 0.25% WRMS (JIS WTD),
3 kHz
at 33
1/3
rpm
USB port
USB 1.1 for WINDOWS, MAC
OSX
Frequency range
20 Hz ... 20 kHz
+1/-3 dB
Phono output level
1.5 - 3.6 mV at 1 kHz
Line output level
129 - 313 mV at 1 kHz
