HDS User Manual
(HTT06291133)
When this mode is selected a Test box will appear.
G-code commands can be entered in this box, then clicking Cycle Start will run the command.
Eg,
G0 X10Y10 in the box then Cycle start will move the machine to X10 Y10
M3 S18000 will turn on the spindle at a speed of 18000rpm
M5 will turn off the spindle.
(UAO,03) will activate Origin 3
M6 T4 will pick up tool 4
MDI mode stands for
Manual Data Input.
Activate this mode by
clicking the icon in the
Jog box. MDI.
