HDS User Manual
(HTT06291133)
Addendum:
HDS Drill Bank Machine
29 Trade Zone Drive, Ronkonkoma NY 11779
Office: (631) 648-7481
www.technocnc.com
5. Depending on the length of the drills, you must input 1 of 3 lengths. See the
table below.
Drill Tool Length in mm Z-Offset
57mm -8.55352
70mm -8.04171
77mm -7.79912
These values must be inputted for ALL the drill bank tools. This means you
must input the SAME number in “Z-Offset” for tools 11 through 19. To edit
the “Z-Offset”, click on the tool number in the table then manually input the
value from the table above into the field marked “Z-Offset”. Click apply when
you are done.
6.1 Addendum: HDS Drill Bank Machine
