Techno HDS Series - Page 53

For Support Visit· support.technocnc.com or Call: (631) 648-7481
53
HDS User Manual
(HTT06291133)
Addendum:
HDS Drill Bank Machine
29 Trade Zone Drive, Ronkonkoma NY 11779
Office: (631) 648-7481
www.technocnc.com
Offset (Tool #) Z Offset Y Offset X Offset
1 Use AutoTouchoff 1 -1.37339 -8.33738
2 Use AutoTouch off 2 -1.37339 -8.33738
3
Use AutoTouch off 3
-1.37339
-8.33738
4
Use AutoTouch off 4
-1.37339
-8.33738
5 Use AutoTouch off 5 -1.37339 -8.33738
6 Use AutoTouch off 6 -1.37339 -8.33738
7 Use AutoTouch off 7 -1.37339 -8.33738
8 Use AutoTouch off 8 -1.37339 -8.33738
11
Z-Offset Depends on
Drill Bit Length.
See Table Above for
Proper Value
0.00000 0.00000
12 -1.25984 0.00000
13 -2.51969 0.00000
14
-3.77953
0.00000
15 -5.03937 0.00000
16 -5.03937 1.25984
17 -5.03937 2.51969
18 -5.03937 3.77953
19 -5.03937 5.03937
6.1 Addendum: HDS Drill Bank Machine
