1.4.4
Attach the three phases and
the earth to the connections
showning1.4.4.
1.4.5
Variouscomponentsonthemachinerequireair
pressure. 90psi of air needs to be supplied to the
machine for it to function correctly.
Attach an air hose to the air input on the back of the
machine.Seeg1.4.5.
Ifyourshophosedoesnotttheadaptorsupplied,the
adapter can be removed and a suitable one attached.
The threading on the machine is standard 3/8 female.
Amalethreaded3/8ttingtoattachtoyourfactoryair
hose can be purchased at most hardware stores.
3 phase
220V in
90 psi in
WARNING: Ensure that all electrical connections are
carried out by a qualied electrician.
Improper electrical connections can result in
damage to the equipment, re and death.
Fig 1.4.4.
Fig 1.4.5.
