EN2
A - Display
A1 – Indoor humidity A2 – Indoor temperature
A3 – WIFI signal icon A4 – Sunset / sunrise
A5 – Time A6 – Alarm 1 / 2 / 3
A7 – UV A8 – Weather forecast
A9 – Air pressure / hPa A10 – Sensor number (1 / 2 / 3)
A11 – Auto scrolling enabled A12 – Outdoor sensor signal
A13 – Outdoor humidity A14 – Outdoor temperature
A15 – Date and month A16 – Weekday
A17 – Low battery indicator A18 – HI – LO values
B - Buttons and back view
B1 – Light sensor B2 – -/MEM button
B3 – SET button B4 – Snooze/WIFI button
B5 – ALM 123 / SET ON/OFF button B6 – +/Out Sensors button
B7 – Heat release vents B8 – DC hole
B9 – AC/DC adaptor B10 – AC wall socket
C – Outdoor sensor
C1 – Holder C2 – Channel button
C3 – Channel 3 C4 – Channel 2
C5 – Channel 1 C6 – Battery compartment
C7 – Indentation (Wall mounting) C8 – Indentation (Table standing)
