TS-7400/TS-9441 MANUAL

INTRODUCTION

KB data cache to provide zero-cycle latency to the current program and data, or they can

be locked to guarantee no-latency access to critical sections of instructions and data. For

applications with instruction-memory size restrictions, the ARM920T’s compressed Thumb

instruction set can be used to provide higher code density and lower Flash storage

requirements.

As a benchmark, the TS-7400's CPU integer performance, at a supplied 200 MHz, is

about twice as fast as the Technologic Systems 133MHz 586-based products.

1.4 Features

The TS-7400 comes standard with these features:

✔ TS-Linux Embedded Operating System Installed

✔ 200 MHz ARM9 CPU with MMU

✔ 32 MB integrated high-speed flash with hardware ECC (Boots to TS-Linux)

✔ 32 MB RAM (64 MB or 128 MB optional)

✔ 2 USB 2.0 Compatible OHCI ports (12 Mbit/s Max)

✔ 3 TTL serial UARTs

✔ SD Flash card connector

✔ 10/100 Megabit Ethernet port

✔ 20 general purpose I/O pins with Schmitt trigger

✔ Power requirements are 5V DC @ 350mA

✔ Flexible 40 pin expansion connector

✔ Small size 2.9 x 4.7 inches (7.4 x 11.9 cm)

✔ Optional battery-backed real time clock

✔ Operating Temperature Range: Fanless from -40° to +70°C

✔ Extended Temperature -40° to +85°C standard at lower CPU clock speeds

✔ RoHS Compliant

1.5 Configurability

The TS-7400 can be configured for your application using the following available on-board

options and external accessories:

On-board Options

✔ TS-7400-yyy-32F: TS-7400 with up to 128 MB of on-board SDRAM. For example, TS-

7400-64-32F selects model TS-7400 with 64 MB of SDRAM.

✔ OP-BBRTC: on-board sealed battery backed RTC

✔ OP-PS30V : 8-30VDC switching power input through screw terminal

✔ OP-TMPSENSE: High-precision temperature sensor

Note

The TS-7400 SBC is RoHS compliant by default (Restriction of Hazardous

Substances ) Directive. Contact Technologic Systems for RoHS support.

External Accessories

✔ SD-512: 512 MB SD Flash Card with full ARM tool chain installed and Debian (included

in KIT-7400)
