TECHTOP TD20 Series - 2.5 Rated specifications

TD20 Series VFD Product Overview
-8-
TD20 – 2R2G – 4
① ② ③
TD Figure 2-2 Product type
Key
No.
Detailed description
Detailed content
Product abbreviation
①
Product abbreviation
TD20
TD20 is short for Topdrive20
Rated power
②
Power range + Load type
2R2— 2.2kW
G— Constant torque load
Voltage degree
③
Voltage degree
S1: AC 1PH 110V–120V
S2: AC 1PH 200V–240V
2: AC 3PH 200V–240V
4: AC 3PH 380V–480V
2.5 Rated specifications
Model
Rated
output
power (kW)
Rated
output
horsepower
(HP)
Rated input
current (A)
Rated
output
current (A)
TD20-0R4G-S1
0.4
0.5
8.1
2.5
TD20-0R7G-S1
0.75
1
15.1
4.2
TD20-1R1G-S1
1.1
1.5
20
5.8
TD20-0R4G-S2
0.4
0.5
6.5
2.5
TD20-0R7G-S2
0.75
1
9.3
4.2
TD20-1R5G-S2
1.5
2
15.7
7.5
TD20-2R2G-S2
2.2
3
20
10
TD20-0R4G-2
0.4
0.5
3.7
2.5
TD20-0R7G-2
0.75
1
5.0
4.2
TD20-0R7G-4
0.75
1
3.4
2.5
TD20-1R5G-4
1.5
2
5.0
4.2
TD20-2R2G-4
2.2
3
5.8
5.5
2.6 Structure diagram
Below is the layout figure of the VFD (take the VFD of 0.75kW as the example).
