TD20 Series VFD Function Parameters
-25-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
("LOCAL/REMOT" light off)
Carry out the command control by RUN, STOP/RST on
the keypad.
Set the multi-function key QUICK/JOG to FWD/REVC
shifting function (P07.02=3) to change the running
direction; press RUN and STOP/RST simultaneously in
running state to make the VFD coast to stop.
1: Terminal running command channel
("LOCAL/REMOT" flickering)
Carry out the running command control by the forward
rotation, reverse rotation and forward jogging and
reverse jogging of the multi-function terminals
2: Communication running command channel
("LOCAL/REMOT" on);
The running command is controlled by the upper monitor
via communication
P00.03
Max. output
frequency
This parameter is used to set the maximum output
frequency of the VFD. Users need to pay attention to
this parameter because it is the foundation of the
frequency setting and the speed of acceleration and
deceleration.
Setting range: P00.04–400.00Hz
60.00Hz
◎
P00.04
Upper limit of
the running
frequency
The upper limit of the running frequency is the upper
limit of the output frequency of the VFD which is lower
than or equal to the maximum frequency.
Setting range: P00.05–P00.03 (Max. output frequency)
60.00Hz
◎
P00.05
Lower limit of
the running
frequency
The lower limit of the running frequency is that of the
output frequency of the VFD.
The VFD runs at the lower limit frequency if the set
frequency is lower than the lower limit.
Note: Max. output frequency ≥ Upper limit frequency ≥
Lower limit frequency
Setting range: 0.00Hz–P00.04 (Upper limit of the
running frequency)
0.00Hz
◎
P00.06
A frequency
command
selection
0: Keypad data setting
Modify the value of function code P00.10 (set the
frequency by keypad) to modify the frequency by the
keypad.
1: Analog AI1 setting (corresponding keypad
1
○
P00.07
B frequency
command
2
○
