TD20 Series VFD Function Parameters
-61-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
previous 2
faults
P07.56
Output
terminals state
at previous 2
faults
0
●
P08 Group Enhanced functions
P08.00
ACC time 2
Refer to P00.11 and P00.12 for detailed definition.
TD20 series define four groups of ACC/DEC time which
can be selected by P5 group. The first group of
ACC/DEC time is the factory default one.
Setting range: 0.0–3600.0s
Depend
on
model
○
P08.01
DEC time 2
Depend
on
model
○
P08.02
ACC time 3
Depend
on
model
○
P08.03
DEC time 3
Depend
on
model
○
P08.04
ACC time 4
Depend
on
model
○
P08.05
DEC time 4
Depend
on
model
○
P08.06
Jogging
running
frequency
This parameter is used to define the reference
frequency during jogging.
Setting range: 0.00Hz–P00.03 (the Max. frequency)
5.00Hz
○
P08.07
Jogging
running ACC
time
The jogging ACC time means the time needed if the
VFD runs from 0Hz to the Max. Frequency.
The jogging DEC time means the time needed if the
VFD goes from the Max. Frequency (P00.03) to 0Hz.
Setting range: 0.0–3600.0s
Depend
on
model
○
P08.08
Jogging
running DEC
time
Depend
on
model
○
P08.09
Jumping
frequency 1
When the set frequency is in the range of jumping
frequency, the VFD will run at the edge of the jumping
frequency.
The VFD can avoid the mechanical resonance point by
0.00Hz
○
P08.10
jumping
frequency
0.00Hz
○
