TD20 Series VFD Product Overview
-6-
Function
Specification
output
Output current (A)
Refer to the rated value
Output power (kW)
Refer to the rated value
Output frequency
(Hz)
0–400Hz
Technical
control
feature
Control mode
SVPWM, SVC
Adjustable-speed
ratio
Asynchronous motor 1: 100 (SVC)
Speed control
accuracy
±0.2% (SVC)
Speed fluctuation
±0.3% (SVC)
Torque response
<20ms (SVC)
Torque control
accuracy
10%
Starting torque
0. 5Hz/150% (SVC)
Overload capability
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
Running
control
feature
Frequency setting
method
Digital setting, analog setting, pulse frequency setting,
multi-step speed running setting, simple PLC setting, PID
setting, MODBUS communication setting
Shift between the set combination and set channel.
Auto-adjustment of
the voltage
Keep a stable voltage automatically when the grid voltage
transients
Fault protection
Provide comprehensive fault protection functions:
overcurrent, overvoltage, undervoltage, overheating, phase
loss and overload, etc.
Peripheral
interface
Analog input
1 input (AI2): 0–10V/0–20mA; 1 input (AI3): -10–10V
Analog output
2 inputs (AO1, AO2): 0–10V/0–20mA
Digital input
4 common inputs, max. frequency: 1kHz;
1 high speed input, max. frequency: 50kHz
Digital output
1 Y1 terminal output; 2 programmable relay outputs
Relay output
2 programmable relay outputs
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contact capacity: 3A/AC250V
Others
Mountable method
Wall and rail mountable
Temperature of the
running environment
-10–50°C, derate above 40°C
Protective degree
Note:
