PROVASET T3LPF REV.20210610
12
3.4 Front panel
A LCD Display, Colour TFT, 7” with touch screen;
B
Start/Stop push button, push to start a new test, push again for about 1 s to stop the test.
D Test cycle phase lights
E Lights tower with loud alarm, removable, with 1.5 m cable (semaphore option)
USB Host connector.
B
C
E
A
F
D
do not use sharp or pointed objects on the touch screen, use only
