The display shows:
• clock/calendar: clock/calendar status (top right line), in red if date and time are
not valid, due to prolonged power failure;
• active product: number and name of the tests sequence (product program)
that will be executed at START;
• the regulated pressure for the next test.
Before initializing testing, the operator must check that the parame-
ters of the active test program and the regulated pressure output are safe and
correctly set for the parts to be tested.
Press the START button (if enabled) on the front panel to make a new test.
5.2 Touch screen keys for managing display menus
Press the left-hand arrow key to scroll the pages of the base menu (informa-
tion about the instrument, bar code function, pressure readings).
Press the right-hand arrow key to scroll the pages of the base menu (pres-
sure readings, bar code function, information about the instrument).
Press the [TESTS LOG] key to visualize the results of the last tests.
Press the key [PRODUCT] on the touch screen to read and eventually modify
the parameters of the PRODUCT program that is enabled and active for the
tests.
Press the [GEAR] key to enter the main menu page for all the programmable
functions (test programs, general settings, records, calibration ...)
