5.3 Information pages display
Some of the base menu pages show useful information for the operator.
To display pages, press the keys
Instrument Information:
: instrument code
: version of the soft-
ware.
: full scale limits of the sensors.
: serial number of the instrument.
: date of the last calibration
of the sensors performed by Tecna srl
T3L
1.0.42 - 07/06/2021
030020120113
18-11-20
P: 8 Bar - T(ref): 273.15 K, P(ref): 1013.25 mbar
F: 20 l/min (0 °C)
Model:
Revision Firmware:
Full scale:
Serial number:
Calibration:
INFORMATION
Alarm page: displayed only if alarms are
present; example:
: reprogram the
: repeat the proce-
dure for calibrating the sensors.
pressing on the line that dis-
plays the alarm opens a text page
that contains useful information
for the operator to manage the
alarm.
CONFIGURATION
CALIBRATION
ALARMS
The page displays the status of the digi-
tal outputs on the expansion boards.
The status of the outputs cannot be
changed manually.
1
23 4 567
8
9
10 11 12 13
14
15 16
TEST OUTPUTS
