The page displays the status of the digi-
tal inputs on the expansion boards.
01 02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
TEST INPUTS
21.8
0.0380
0.0124
29.45
0.05
kPa
kPa
l/min
REGULATED
FLOW
SENSORS READING
PRESSURE
Tare
Tare
The page displays the readings of the sensors
Regulated: internal pressure, regulated by the proportioning valve.
Pressure: external test pressure, measured on the component being tested.
Barcode management: example
Barcode 1: operator code
Barcode 2: product code
Barcode 3: production batch code
Barcode 4: serial number of the product
being tested.
3
N123-ABC
11001
L1545
OPERATOR:
BATCH:
PRODUCT:
SERIAL:
BARCODE FUNCTION
5.4 Testing products and programs
The test cycle of a component being tested can be performed using a PRODUCT or a
TEST PROGRAM, to use a PRODUCT access the PRODUCT menu and in the list of avail-
able products enable the desired product by selecting it (see Products page 35),
whereas to use a TEST PROGRAM access the TEST PROGRAMS menu and in the list
of available test programs enable the desired test program by selecting it (see Test
programs page 37).
