PROVASET T3LPF REV.20210610
37
5.4.2 Test programs
Each individual trial of a test sequence (PRODUCT) is performed according to the pa-
rameters of the corresponding TEST program.
The test parameters are displayed on subsequent pages; the presence and functions
of the parameters depend on the type of test selected and the options installed.
List of programs available as TEST
Only when a test program is used to per-
form a test cycle of a component must
the test program be selected in the EN-
ABLE column on the right, a full circle in-
dicates that the test program is active for
testing.
1
2
3
4
5
SHOW
TEST_A
TEST_B
TEST_C
TEST_D
TEST_E
ENABLE
PROGRAMS
Displaying and changing a TEST program
Press on the number or on the name of a TEST to display the parameters of the test
program.
Press the keys
to display the
parameters of the test program in suc-
cession.
Press the key
to change the param-
eters.
Name
Test type
TEST_A
Leak
PROGRAM n°PROG 001:TEST_A
5.4.2.1 Test program: name, type of test, mode
Name of the test program, max 16 alphanumeric characters, can be entered manu-
ally.
Program code, 24 characters max, can be entered manually or with a barcode reader
(option).
Selectable test cycle:
: leak test for absolute pressure drop.
