PROVASET T3LPF REV.20210610
41
If programmed PN = 0, the limit represents the maximum acceptable pres-
as well as the limit represents the mini-
mum pressure.
AT
NO: tare not executed; YES: automatic tare enabled.
it is recommended to enable the automatic calibration function for tests
in "low pressure" mode (
=1)
5.5.4 Flow rate test: PASSED/FAILED result messages
5.5.4.1 PASSED result messages
PASSED
A test ends with a PASSED result if the pressure measured during the time T1 does
the FD+ FD- values which are also set in the test program.
5.5.4.2 FAILED result messages
Each type of test: the test pressure has exceeded by at least 10 % the maximum full-
scale pressure.
5.5.5
limits FD+ and FD-, compared to FN parameter and
the measured pressure is within the pressure limits
PD+ and PD-, compared to PN parameter.
Due to continuous automatic pressure regulation
and perturbation inside measuring system, meas-
ured pressure unlikely will be exactly at PN set val-
ue.
