PROVASET T3LPF REV.20210610
61
6.2 Unit: instrument settings
Selection mode of the active product/program for the tests.
PARAMETER: selection from the product/program menu (box with full circle).
: choice with PLC inputs on expansion boards, counted from 0 (all inputs
at zero, choice of table no. 0, not valid).
: choice with PLC inputs on expansion boards, counted from 1 (all inputs
at zero, choice of table no. 1).
Enable / Disable the button on the front panel.
If the button is disabled, the Start/Reset commands of the tests are managed only by
the PLC inputs or by the commands on the serial lines.
Risk of moving parts;
Disable the Start/Stop button on the front panel if the pneumatic or electrical
outputs are used to control moving parts.
After a test with result
PASSED, the START command of a new test is accepted only
after a RESET command.
After a test with result
, the START command of a new test is accepted only
after a RESET command.
PR_MAX: maximum adjusted test pressure; the maximum test pressure may be re-
duced in relation to the nominal full scale of the instrument; this function may be
used for the safe testing of components which cannot withstand full scale pressure.
Applicable for printing reports and serial line communication.
Before performing a test, the instrument checks whether the serial connection to a
PC or to a server over Ethernet is active.
No: Communication is not checked before starting a test.
Yes: If communication is not active, Start commands are not accepted.
Demonstration mode or normal use.
No: Normal use for testing.
Yes: Demonstration use, tests are simulated automatically but are not performed.
