Tecnam P92 Echo Super - General Aircraft Information

P92 Echo Super
G E N E R A L
F LIG HT MANUAL
2
nd
edition, October 2004 Doc. n° 92-13-021-01
1-3
THREE VIEW DRAWING
• Dimensions shown refer to aircraft weight of 450 kg and normal operat-
ing tire pressure.
• Propeller clearance 360mm
• Propeller clearance with deflated front tire and compressed shock ab-
sorber 142mm
• Minimum ground steering radius 5.5m
