CLEANING AND MAINTENANCE
This washing machine does not require any particular maintenance. At the end of each wash
it is recommended to leave the door open so that air will circulate and dry the interior of the
machine. The external part of the machine should never be cleaned with abrasive detergents
since this would ruin the enamel coating as well as the synthetic parts.
Removing and cleaning filter
Place a rag under the washing machine to absorb any residual
water. The filter is located under the base. Turn the filter handle
counterclockwise and pull out the filter. Clean it under running
water. Reinsert the filter and turn the handle clockwise until it is
completely locked. WARNING: Water may leak from the filter if it
is not properly tightened. Remember to clean the filter frequently
to avoid excessive clogging.
TEL. 08705 678910
BEFORE CALLING THE TECHNICAL SERVICE CENTER:
– Check if plug is inserted
– Check that power is available
– Check that the door is properly closed
– Check that the water tap is open
– Check that the water supply hose and water drain hose
– Are not blocked
– Check that the pump filter is clean
NOTE: If you have to call the service center, specify the model
of your washing machine and if necessary the serial number
which is indicated on the rating plate on the reverse of the
porthole door and on the rear side of the machine.
Technical features
dry clothes washing capacity 5 kg (11 lb)
height 850 mm (33 in)
width 595 mm (23.5 in)
depth (piping included) 530 mm (20.9 in)
total net weight 62 kg (136 lb) approx
motor 350-500 watt
water draining pump 25 watt
water heating element 2500 watt
supply voltage 230..240 V - 50 Hz
power rating 2850 watt approx
safety fuse 13 A
water pressure min. 0,1 Mpa (1 bar)
max. 1 Mpa (10 bar)
max cotton/linen load: Washing 5Kg Drying 2,5Kg
max delicates/synthetic load: Washing 2,5Kg Drying 1,5Kg
max wool load: Washing 1Kg Drying -
