9
Remove safety caps.
Connect the hose to the appliance (O) fitting also
the rubber gasket. Connect the other side to the
feeding cock.
OPTIONAL: emergency water block system
(WATER BLOCK). Such device shall be vertically
mounted immediately downstream the feeding
cock.
See the device instructions for further
information on the tool installation and use.
Water drain hose.
Remove the safety cap. Connect the hose to the
device (P).
Connect the other end to the
discharge. Fix it safely and securely.
Install the siphon as shown in the figure
Detergent reservoir drain hose
Take the transparent drain hose to a visible point at the same height of the appliance
leaning plane or under it. Do not obstruct nor keep it immerged into the fluid. The drain
hose has also an overflow function, when the detergent reservoir is full, if some more
detergent is injected the drain hose discharges it.
