______________________________________________________________________________ STARGAS
OPERATING INSTRUCTIONS 31
2.0 - HOW TO CONNECT THE STARGAS
To connect the STARGAS:
• Remove the tool form the package and place it in the special trolley housing
(option).
The package should be kept in case that you need it again subsequently to
transport the tool.
• Connect the RPM battery cable (46) to the RPM socket (22).
• Connect the ground cable (44) to the COM port (26).
• Connect the temperature probe (45) (option) to the TEMP.°C tap (23).
• Attach the battery supply cable (43) to the battery socket (31) and to the tested
vehicle battery (in case the vehicle is not already supplied by the mains cable).
• Attach the mains cable (47) to the mains socket (33) and to the supply source
of the power mains (in case the vehicle is not already supplied by battery cable).
• For the connection to the feeding mains, make sure that the tap has the same
VOLTAGE/FREQUENCE features as those that are written on the plate which is
located on the tool back side. The earthing is absolutely necessary.
