STARGAS _______________________________________________________________________________
30 OPERATING INSTRUCTIONS
1.2 - Tool rear view
14. Filter-holder with internal cooling air filter that can be washed.
15. Main switch: to turn on and off the tool if plugged to a battery.
16. Certification plate: All of the technical features can be found there.
17. COM1 Port: serial port for the connection to the autodiagnosis interface.
18. COM2 Port: serial port for the connection to the autodiagnosis interface.
19. PARALLEL port: Port for the connection to a 80-column standard printer.
20. Port for special activations by electronic key.
21. RS485 port: Port for industrial standard serial connection.
22. RPM Socket: Socket for the connection of the RPM clamp from battery or of
induction clamp (option).
23. TEMP Socket: Socket for the connection of the oil temperature probe (option).
24. Ambient sensors: Sensors to detect environment data (relative humidity and
temperature).
25. λ Socket: Socket for the connection of the lambda probe 1 Volt/5 Volt.
It cannot be used in this version (STARGAS LIGHT).
26. COM port: Port for the vehicle ground connection; battery negative.
27. Oscilloscope connector BNC: It allows the inlet of the measured signal through
the relevant wire connection.
28. VGA port: Port for the connection to a standard monitor or to a TV color
(PAL/NTSC systems).
29. RS232/PC port: Port for the connection to a Personal Computer.
30. SMOKEMETER port: Port for the connection to a partial flow smoke analysis cell
combined with external supplier.
31. Battery Socket: Tool power socket by the connection of the relevant battery
cable (12 Volt).
32. Fuse compartment with a 5 A quick fuse.
33. Mains Socket: Tool power supply socket by the connection of the relevant cable
to the power mains.
34. Main switch: to turn on and off the tool if plugged to the mains supply.
