3.9. AUXILIARY DEVICES
3.9.1. Please refer to your specification and the motor nameplate to determine if
the motor is fitted with thermal winding protection devices.
The following are the most common:
One set (one per phase – total 3 off) of PTC winding thermistors.
Two sets (two per phase – total 6 off) of PTC winding thermistors.
One set (one per phase – total 3 off) of PT100 winding Resistance
Temperature Detectors (RTD’s).
Two sets (two per phase – total 6 off) of PT100 winding Resistance
Temperature Detectors (RTD’s).
3.9.2. Where specified motors may also be equipped with PT100 bearing
Resistance Temperature Detectors (RTD’s).
3.9.3. Thermistors are positive temperature coefficient type (1000 ohm @ tripping
temperature) refer to specification table for tripping temperature.
They are a tripping device only and not a temperature detector.
Thermistor leads should be connected to an appropriate thermistor control
relay from a reputable supplier.
3.9.4. RTD’s where fitted are of the platinum type (PT100) with a reference
temperature of 0°C at 100.
RTD leads should be connected to an appropriate motor protection system
from a reputable supplier.
Recommended temperature settings for RTD’s are as per table 2 below.
DEVICE
TYPE
LOCATION
ALARM
TRIP
RTD
PLATINIUM 100 @ 0
O
C
WINDING
140
0
C
150
0
C
RTD
PLATINIUM 100 @ 0
O
C
DE & NDE BEARING
90
0
C
95
0
C
Table 2
