DMX-512 Connections
The DMX-512 is widely used in intelligent lighting control with a
maximum of 512 channels.
Temperature reduces signal error and avoids signal transmis-
sion problems and interference. It is always advisable to con-
nect a DMX terminal.
(Resistance 120 ohm 1/4W) between pin2 (DMX-) and pin3
(DMX+) of the last xture
6CH Channel mode
p. 8NEBULA 6 - 12W * 6PCS LED PAR LIGHT
English Version
