Specifications Model P3297
Pressure ranges bar 1 1.6 2.5 4 6 10 16 25
Over pressure safety bar 2 3.2 5 8 12 20 32 50
Burst pressure bar 5 10 10 17 34 34 100 100
Pressure ranges bar 40 60 100 160 250 400 600
Over pressure safety bar 80 120 200 320 500 800 1200
Burst pressure bar 400 550 800 1000 1200 1700 2400
MPa and kg/cm
2
are available
{Absolute pressure: 0 ... 1 bar up to 0 ... 25 bar;
compound ranges: -1 ... 0 bar up to -1 ... 24 bar}
Pressure ranges psi 15 25 30 50 100 160 200 300
Over pressure safety psi 30 60 60 100 200 290 400 600
Burst pressure psi 75 150 150 250 500 500 1500 1500
Pressure ranges psi 500 1000 1500 2000 3000 5000 10000
Over pressure safety psi 1000 1740 2900 4000 6000 10000 17400
Burst pressure psi 2500 7975 11600 14500 17400 24650 34800
{Absolute pressure: 0 ... 15 psi up to 0 ... 300 psi}
{+/- Measuring range: -30 inHg ... 0 psi to -30 inHg ... 300 psi}
Vacuum resistance from 10 bar
Fatigue life 10 Mio. load cycles
Materials
 Wetted parts
» Pressure connection 316 L
» Pressure sensor 316 L (as of 0 ... 10 bar rel 13-8 PH)
 Internal transmission fluid
Silicone oil (only with pressure ranges < 0 ... 10 bar and
≤ 0 ... 25 bar abs)
Case 316 L
